RainTEC Center Pivot Components

Home > New Products

Download Product Brochure








Raintec® Pivot Cable

• Power supply to center pivots, electric well • Aluminum wire sizes from #4 to 350MCM AWG with motors, and other applications cross-linked polyethylene insulation

• Compact construction = more wire per roll • Heavy-duty outer jacket is rodent-repellant PVC
• Light weight and flexibility make it easier to handle

• (Optional) Copper wires are #12 AWG with than cable in duct type constructions PVC insulation

• Sequentially marked in feet • Aluminum wires color coded red, white, yellow, black

• Heat and moisture resistant for wet or dry locations • (Optional) Copper wires coded black and white

• (Optional) remote pump control wires
Standards Specifications • NMX-J-010: Specs for 600V thermoplastic PVC cables • Maximum Conductor Operating Temperatures: 90°C • NMX-J-451: Specs for 600V XLPE insulated cables • Maximum Operating Voltage: 600V

Call Today for Pricing!





RainTEC Cable

NI Part # Construction Description
250123R 4-#4 Tulsa
250118R 4-#4 2-#12 Tulsa w/ pump control wires
250156R 3-#2 1-#4 Dyke
250155R 3-#2 1-#4
2-#12
Dyke w/ pump control wires
250126R 3-#1/0 1-#2 Notre Dame
250134R 3-#1/0 1-#2
2-#12
Notre Dame w/ pump control wires
250125R 3-#2/0 1-#1 Syracuse
250152R 3-#250MCM
1-#3/0
Rust
250153R

3-#350MCM
1-#4/0

Slippery Rock















Nebraska Irrigation is pleased to introduce the new Senninger Xi-wob provides the same ultra-low application intensity that has made the Senninger I-Wob the leading pivot sprinkler on the market. The Xi-wob is specifically designed for use on rigid polyethylene or steel drops, utilizing a patented counter-balance technology which eliminates the need for flexible hose on the drop.



Designed specifically for use on rigid PE or steel drops
Ultra-low application intensity to preserve soil integrity
Excellent distance of throw; up to 46' in diameter
Two different groove geometries provide application flexibility
Low pressure operation (10 – 15 psi) saves money and energy
Utilizes Senninger I-Wob technology proven for excellent performance and durability
Backed by Senninger’s 2-year warranty and renowned service








Wing End Gun


Outstanding Features and Benefits
• Bottom bearing assembly is supported by bronze bearings with stainless steel balls providing excellent life.
• Drive arm stroke can be easily adjusted.
• Directional spoons are smooth to eliminate possible blockage.
• Adjustable stops - no tools required.
• Low pressure applications.
• Excellent uniformity.
• Full or part circle applications.
• 2" NPT base.
• 18º Trajectory.
• Slow reverse.


Cutaway of bottom bearing assembly on Wing End Gun.

Sime Wing
Nozzle Performance Data
Size Inch
PSI
Dia. Ft.
GPM
12
0.47
29
144
33.5
44
167.2
40.9
56
190
47.3
70
210
53.3
85
226
58.4
14
0.55
29
157.4
45.9
44
190
56
56
210
64.7
70
232
72.4
85
246
79.2
16
0.63
29
164
59.7
44
200
72.9
56
226
84.5
70
246
94
85
262
103.3
18
0.71
29
174
75.5
44
210
92.4
56
239.4
106.7
70
262
119.4
85
282
130.7
20
0.78

44

216

114.1

56
246
132.3
70
269
147.9
85
292
161.9
100
301.8
174.6
22
0.86
44
222
137.9
56
259.2
159.5
70
285.4
178.6
85
311.6
195.7
100
328
211
24
0.95
44
229.6
164.6
56
265.6
190.2
70
298
212.9
85
324
233
100
341.2
251.5





Raintec Booster Pumps

NI is pleased to anounce that we have exclusive rights to distribute RainTEC booster pumps. Top quality, & interchangable part for part with Berkeley Booster


End Gun Booster Pumps
NI Part # Description
89561 2 HP - 130 GPM End Gun Booster
89515 5 HP - 130 GPM End Gun Booster, High Head
89507 5 HP - 200 GPM End Gun Booster
89516 7.5 HP - 200 GPM End Gun Booster, High Head

Parts available for above pumps. Contact us for details.
